PF CRUSHER

Im(Int)pac(rod)t(u)cc(t)iru(o)s(n)her can be applied  in the first and secondary crushing  process,dealing with the

materials of which the compression strength is not more than 350Mpa,like

granite,basalt,iron  ore,manganese  ore,limestone,gold  ore,concrete  etc.The  utility  model  has the  advantages  of  large  crushing  ratio,good  broken  granular  shape,compact  structure,

reliable  performance,long  hammer  life  and  convenient  maintenance.Therefore,it  is  widely used   in   railways,highways,cement,mining,chemical,construction   and   other    industries.

Working Principle

Impact crusher is a crushing machine that uses impact energy to crush materials.the rotors driven by the motor power to rotates with a high speed.When the materials enter the

working area,they will be impacted by the board hammers on the rotor and be thrown onto the impact plate.The materials which spring back from the impact plate will be struck by

the board hammers again until they reach the desired size,after which the materials will fall through the screen  plate  under the  rotor.The  crushed  materials  which  meets  the  required   size will  be discharged from the outlet.
